| بطاقة تعريف | تسامح | سماكة | ضغط العمل | الضغط الانفجاري | وزن | |||
| بوصة | مم | مم | بوصة | مم | رطل لكل بوصة مربعة/بار | رطل لكل بوصة مربعة/بار | رطل / قدم | كجم/م |
| 2'' | 50 | 52.8-54.8 | 0.098 | 2.50 | 250/17 | 750/51 | 0.356 | 0.53 |
| 2'' | 50 | 52.8-54.8 | 0.106 | 2.70 | 250/17 | 750/51 | 0.390 | 0.58 |
| 2'' | 50 | 52.8-54.8 | 0.118 | 3.00 | 410/28 | 1230/84 | 0.403 | 0.60 |
| 2.5 بوصة | 65 | 63.5-65.5 | 0.110 | 2.80 | 250/17 | 750/51 | 0.410 | 0.61 |
| 3'' | 80 | 76.0-78.0 | 0.098 | 2.50 | 150/10 | 450/30 | 0.470 | 0.70 |
| 3'' | 80 | 76.0-78.0 | 0.110 | 2.80 | 250/17 | 750/51 | 0.504 | 0.75 |
| 3'' | 80 | 76.0-78.0 | 0.114 | 2.90 | 300/20 | 900/60 | 0.538 | 0.80 |
| 3'' | 80 | 76.0-78.0 | 0.142 | 3.60 | 410/28 | 1230/84 | 0.625 | 0.93 |
| 4' | 100 | 102-104.5 | 0.110 | 2.80 | 150/10 | 450/30 | 0.685 | 1.02 |
| 4' | 100 | 102-104.5 | 0.126 | 3.20 | 250/17 | 750/51 | 0.806 | 1.20 |
|---|---|---|---|---|---|---|---|---|
| 4' | 100 | 102-104.5 | 0.150 | 3.80 | 300/20 | 900/60 | 0.941 | 1.40 |
| 4' | 100 | 102-104.5 | 0.169 | 4.30 | 410/28 | 1230/84 | 1.109 | 1.65 |
| 4' | 100 | 102-104.5 | 0.217 | 5.50 | 610/42 | 1830/126 | 1.331 | 1.98 |
| 5 بوصة | 125 | 127-129 | 0.118 | 3.00 | 150/10 | 450/30 | 0.941 | 1.40 |
| 5 بوصة | 125 | 127-129 | 0.126 | 3.20 | 200/14 | 600/42 | 1.075 | 1.60 |
| 6 بوصة | 150 | 152-154 | 0.118 | 3.00 | 150/10 | 450/30 | 1.109 | 1.65 |
| 6 بوصة | 150 | 152-154 | 0.138 | 3.50 | 200/14 | 600/42 | 1.277 | 1.90 |
| 6 بوصة | 150 | 152-154 | 0.150 | 3.80 | 250/17 | 750/51 | 1.344 | 2.00 |
| 6 بوصة | 150 | 152-154 | 0.161 | 4.10 | 300/20 | 900/60 | 1.613 | 2.40 |
| 6 بوصة | 150 | 152-154 | 0.228 | 5.80 | 410/28 | 1230/84 | 2.150 | 3.20 |
| 6 بوصة | 150 | 152-154 | 0.236 | 6.00 | 480/33 | 1440/100 | 2.285 | 3.40 |
| 8' | 200 | 203.5-205.5 | 0.106 | 2.70 | 100/7 | 300/21 | 1.277 | 1.90 |
| 8' | 200 | 203.5-205.5 | 0.134 | 3.40 | 150/10 | 450/30 | 1.546 | 2.30 |
| 8' | 200 | 203.5-205.5 | 0.150 | 3.80 | 200/14 | 600/42 | 1.949 | 2.90 |
| 8' | 200 | 203.5-205.5 | 0.165 | 4.20 | 250/17 | 750/51 | 2.150 | 3.20 |
| 8' | 200 | 203.5-205.5 | 0.173 | 4.40 | 300/20 | 900/60 | 2.285 | 3.40 |
| 8' | 200 | 203.5-205.5 | 0.224 | 5.70 | 410/28 | 1230/84 | 2.957 | 4.40 |
| 10' | 250 | 254-257 | 0.102 | 2.60 | 70/5 | 210/15 | 1.680 | 2.50 |
| 10' | 250 | 254-257 | 0.130 | 3.30 | 150/10 | 450/30 | 2.016 | 3.00 |
| 10' | 250 | 254-257 | 0.157 | 4.00 | 200/14 | 600/42 | 2.554 | 3.80 |
| 10' | 250 | 254-257 | 0.173 | 4.40 | 250/17 | 750/51 | 2.957 | 4.40 |
| 10' | 250 | 254-257 | 0.193 | 4.90 | 300/20 | 900/60 | 3.360 | 5.00 |
| 12' | 300 | 305-308 | 0.110 | 2.80 | 70/5 | 210/15 | 1.882 | 2.80 |
| 12' | 300 | 305-308 | 0.161 | 4.10 | 150/10 | 450/30 | 2.957 | 4.40 |
| 12' | 300 | 305-308 | 0.169 | 4.30 | 200/14 | 600/42 | 3.360 | 5.00 |
| 12' | 300 | 305-308 | 0.197 | 5.00 | 250/17 | 750/51 | 3.696 | 5.50 |
| 12' | 300 | 305-308 | 0.213 | 5.40 | 300/20 | 900/60 | 4.368 | 6.50 |
| 14' | 350 | 359-364 | 0.165 | 4.20 | 150/10 | 450/30 | 3.696 | 5.50 |
| 14' | 350 | 359-364 | 0.197 | 5.00 | 250/17 | 750/51 | 4.435 | 6.60 |
| 16' | 400 | 412-417 | 0.130 | 3.30 | 100/7 | 300/21 | 3.226 | 4.80 |
| 16' | 400 | 412-417 | 0.161 | 4.10 | 150/10 | 450/30 | 4.032 | 6.00 |
| 16' | 400 | 412-417 | 0.220 | 5.60 | 200/14 | 600/42 | 5.242 | 7.80 |
| 20' | 500 | 510-516 | 0.177 | 4.50 | 120/8 | 360/25 | 5.510 | 8.20 |
